| Parameter | Specification |
|---|---|
| Number of Channels | 1 |
| Frequency | 100 / 50 / 38 / 25 MHz |
| Positioning | Manual, GPS/GNSS, Wireless wheel |
| Performance | Single-unit low-frequency GPR with changeable antenna frequency |
| Antenna Length | 1 m to 4 m (depends on selected frequency) |
| Time Range | 5 - 10000 ns with 18 ps step |
| Pulse Repetition Frequency | 50 - 115 KHz |
| Hardware Stacking | 4 - 65536 |
| Scan Rate | Up to 2500 |
| Samples per Scan | 512 - 8192 |
| Digital Data Display | 32 bits per sample |
| Filters | High-pass digital filter |
| Data Transmission | WiFi |
| Input Power | Built-in Li-Po battery |
| Weight | 8 kg - 18 kg (depends on selected frequency) |
| Receiver Sensitivity | 15 µV |
| Receiver Gain | 15 dB |
| Transmitter Output | 75 V |
| Power Consumption | 0.6 A·h @ 12 V (up to 12 hours per charge) |
| Resolution & Depth | 1-4 × 25-60 m |
